9 Litre: Specifications
Meter Controlled Valve
Settings: Meter immediate, Meter Delayed, Day
Override, Holiday Mode
Mains Powered
Supplied with UK standard plug
Tank Capacity
Contains 9 Litres of fine mesh NSF 44 certified water softening resin
Rated Service Flow
1m3/H / 1000 Litres per hour for softened water to
NSF 44 standard (at 342mg/l incoming hardness)
Max Flow Rate Through Valve
4.5 – 5.9 m3/H / 4500 – 5900 Litres per hour / 75 – 95 Litres per minute
Operating Pressure
Minimum: 1.4 Bar – Maximum: 8.4 Bar
Salt Storage Capacity
21KG
Salt Used Per Regeneration
up to 0.9KG
Salt Type
Salt tablets (must be water softer salt, to BS /EN973 Type A specification)
Litres Between Regenerations
Dependant upon hardness – Example @ 200mg/lup to 1500 litres, @ 300mg/l up to 1000 Litres
Approvals
WRAS Approved control valve and internal tank.
21 Litre: Specifications
Meter Controlled Valve
Settings: Meter immediate, Meter Delayed, Day
Override, Holiday Mode
Mains Powered
Supplied with UK standard plug
Tank Capacity
Contains 21 Litres of fine mesh NSF 44 certified water softening resin
Rated Service Flow
1.7m3/H / 1700 Litres per hour for softened water to NSF 44 standard (at 342mg/lincoming hardness)
Max Flow Rate Through Valve
4.5 – 5.9 m3/H / 4500 – 5900 Litres per hour / 75 – 95 Litres per minute
Operating Pressure
Minimum: 1.4 Bar – Maximum: 8.4 Bar
Salt Storage Capacity
46KG
Salt Used Per Regeneration
up to 2KG
Salt Type
Salt tablets (must be water softer salt, to BS /EN973 Type A specification)
Litres Between Regenerations
Dependant upon hardness – Example @ 200mg/l up to 5550 Litres, @ 300mg/l up to 3700 Litres
Approvals
WRAS Approved control valve and internal tank.
